FLEX-4.5

FLEX-4.5 separator for cleaning and grading seed and food grain, with capacity up to 4.5 t/h.

Back to equipment

Specifications

Capacity, t/h	Machine mass, kg	Width, mm	Length, mm	Height, mm	Total power, kW
Wheat under standard conditions	2400	4110	4800/7800	3000	6,3/7,4
Stationary version	1800	2350	3275	2800	5,2

Type	Self-contained stationary machine
Drive	Electric
Supply voltage	380 V, 50 Hz, AC
Total installed power, kW	6,3 / 7,4
Aspiration elevator drive, kW	3,0
Sieve and trier unit drive, kW	2,2
Movement drive, kW	1,1
Unloading drive, kW	1,1
Specific electricity consumption, kWh/t	1,4

Sieve unit
Number of sieve units	1
Number of tiers	2
Oscillation amplitude, mm	±7,5
Oscillation frequency, rpm	414±10; 351±10
Inclination angle, °	6
Number of sieves	4
Number of brushes	12
Sieve size, mm	790±2,5 × 990±3
Sieve area, m²	3,1
Trier unit
Oat trier
Diameter, mm	600±3
Length, mm	2250±3
Cell diameter, mm	9,5
Cockle trier
Diameter, mm	600±3
Length, mm	2250±3
Cell diameter, mm	5,0
Loading conveyor
Chain conveyor	1
Chain conveyor length, mm	5890
Screw feeder	2
Screw diameter, mm	160
Sieve unit drive
Quantity	1
Power, kW	2,2
Rotation speed, rpm	1410±10
Aspiration
Number of aspiration channels	2
Aspiration channel No. 1, mm	100±2 × 900±2
Fan diameter, mm	Ø300 × 876
Number of blades	12
Aspiration channel No. 2, mm	100±2 × 900±2
Elevator
Number of flows	1
Number of buckets	26
Air system drive
Quantity	1
Power, kW	3,0
Rotation speed, rpm	960±10
Movement mechanism
Working speed, m/s	0,05
Transport speed, m/s	0,22
Unloading conveyor
Quantity	1
Drive drum diameter, mm	430±10
Nominal drum diameter, mm	445
Belt width, mm	180±10
Maximum capacity, t/h	4,5

FLEX-4.5 separator for cleaning and grading seed and food grain, with capacity up to 4.5 t/h.

The machine combines sieve cleaning, aspiration and trier grading in a single process unit.

The design is intended for stable processing of grain and seed crops at specified feed parameters.

Working units and operating modes are selected according to the crop, initial impurity level and required cleaning quality.

The layout provides convenient access to the main units for adjustment, inspection and maintenance.

Seed category	ЭС, РС, РСт
Main waste, %	5
Second fraction	According to the specified process mode
Seed breakage, %	0,2
Corn and sunflower purity, %	98
Grain purity, %	97
Rapeseed, %	96
Main losses, %	4,0
Seed breakage, %	0,08
Hard-to-separate rice impurities, %	3,0
Peas, %	1,0
Buckwheat and oats, %	5,0
Millet, %	10,0
Weed seeds in peas, %	5
Buckwheat, %	80
Flax, %	1700
Rapeseed, %	320
Millet, %	150
Wheat, rye, barley and oats, %	70
Rice, %	100
Sunflower, %	5

FLEX-4.5 consists of a loading unit, sieve unit, aspiration system, triers, elevator and unloading conveyor.

The main units are mounted in a single stationary layout. The process flow passes through cleaning, separation and product unloading in sequence.
